Chain Link Fencing
United Glory Chain Link Fence
UGI Chain Link Fenceis one of the most widely trusted, traditional perimeter solutions for securing large boundaries. Fabricated using high-tensile steel wire woven into a classic diamond mesh pattern, this fence provides a continuous, flexible barrier that easily adapts to uneven terrains and steep slopes without losing structural integrity.
Technical Features & Benefits
01
Flexible Diamond-Weave Mesh
Woven interlocking design allows the fence to flex naturally, adapting flawlessly to uneven ground surfaces, slopes, and hillside terrains.
02
Highly Cost-Effective Security
Provides an economical boundary solution for securing extensive property perimeters without compromising on basic structural strength.
03
Excellent Airflow & Visibility
The open diamond pattern ensures unobstructed line-of-sight for CCTV surveillance and security patrols while allowing maximum natural ventilation.
04
Corrosion-Resistant Options
Available in heavy Hot-Dip Galvanized (HDG) or premium weather-resistant PVC coatings to withstand harsh outdoor weathering and tropical climates.
Specification Table
PVC Coated Galvanized Wire Chain Link:
| Wire Size (SWG) | Wire Diameter (mm) | Width (m) | Length (m) |
|---|---|---|---|
| 8 | 3.90 – 4.50 | 0.90 -7.00 | 10.00 – 15.00 |
| 9 | 3.33 – 3.80 | 0.90 – 7.00 | 10.00 – 15.00 |
| 10 | 3.00 – 3.20 | 0.90 – 7.00 | 10.00 – 15.00 |
| 11 | 2.70 – 2.90 | 0.90 – 7.00 | 10.00 – 15.00 |
| 12 | 2.40 – 2.60 | 0.90 – 7.00 | 10.00 – 15.00 |
Galvanized Chain Link:
| Wire Size (SWG) | Wire Diameter (mm) | Width (m) | Length (m) |
|---|---|---|---|
| 8 | 3.90 – 4.00 | 0.90 -7.00 | 10.00 – 15.00 |
| 9 | 3.30 – 3.80 | 0.90 -7.00 | 10.00 – 15.00 |
| 10 | 3.00 – 3.20 | 0.90 -7.00 | 10.00 – 15.00 |
| 11 | 2.70 – 2.90 | 0.90 -7.00 | 10.00 – 15.00 |
| 12 | 2.40 – 2.60 | 0.90 -7.00 | 10.00 – 15.00 |
| 13 | 22.20 – 2.30 | 0.90 -7.00 | 10.00 – 15.00 |
| 14 | 2.00 – 2.10 | 0.90 -7.00 | 10.00 – 15.00 |
| 15 | 1.80 – 1.90 | 0.90 -7.00 | 10.00 – 15.00 |
| 16 | 1.60 – 1.70 | 0.90 -7.00 | 10.00 – 15.00 |
Available in Hot-Dip Galvanized, Galfan Wire, Heavily Galvanized Wire & Powder Coating. Any Custom-Made Order is Available in our Factory (Minimum Order Quantity may be applied).
